Capacity: 0.1-4t/h
Pressure: Atmospheric pressure
Certificate: ISO 9001, CE, SGS, BV
Fuel: Gas and other oil gas fuels
Ignition 2~4 minutes to get full-pressure steam.
Combustion, steam pressure and water level are all controlled automatically, so the operation is both safe and economical.
Combustion gas flows at high speed between groups of water pipes. Heat convection is good and heat attraction is fast, heat transfer effect is good.
The sound of blower and combustion is 5~6db lower than that of the same type of old products, even if it is operated next to the boiler, it will not be affected.
Furnace structure with good heat absorption effect, combustion thermal efficiency up to 92%~96%.
Full-automatic CO2 welding, consistent production, uniform component specifications, quality assurance.
The whole boiler commissioning factory, on-site installation-free, the equipment arrives at the use of the site can be used after power.
Water pipe temperature can be detected to detect whether the boiler has produced scale, if the temperature is detected to rise to the set temperature, the boiler will automatically stop running.
Can detect the temperature of the steam, when the temperature exceeds the set value of the automatic power-off and shutdown to ensure the safety of boiler operation.
Furnace water concentration conductivity can be detected, when the conductivity reaches the discharge standard, the boiler will automatically discharge the furnace water, stable control of the quality of the furnace water to improve the quality of steam, to avoid caustic embrittlement of the furnace body, scale production to reduce boiler efficiency and water pipe damage.
| del | Steam Capacity (t/h) | Working Pressure (Kgf/cm ) | Boiler Efficiency (%) | Heating Area (m2) | Weight (Kg) | Fuel Consumption | ||
| 13A (Nm3/h) | Propane (Kg/h) | Butane (Kg/h) | ||||||
| LSS0.2 | 0.2 | 10 | 88 | 3.8 | 470 | 12.4 | 10.7 | 11.3 |
| LSS0.3 | 0.3 | 10 | 88/92 | 5.2 | 620/720 | 18 | 15.5 | 16.5 |
| LSS0.5 | 0.5 | 10 | 92/94 | 7.0 | 1060/1060 | 30 | 26 | 27 |
| LSS0.6 | 0.6 | 10 | 92/94 | 7.6 | 1100/1100 | 36 | 31 | 33 |
| LSS1.0 | 1.0 | 10 | 94/96 | 9.9 | 1600/1690 | 85~90 | 73~78 | 77~82 |
| LSS2.0 | 2.0 | 10 | 94/96 | 9.9 | 1980/2000 | 113~121 | 98~105 | 103~110 |
| Notes: 1. The parameter is for reference only, if any changes should follow the actual drawing. | ||||||||
