Thermal capacity: 0.5t/h~6t/h
Rated thermal efficiency: ≥93%
Pressure: 1.0-1.6Mpa
Available fuel: The fuel can fire coal rice husk nut shell sawdust waste wood pieces also can fire wood logs straws.
Available industries: Heat supplying chemical food textile printing and dyeing cigarettes and tobacco fodder pharmacy building materials brewery rubber hospital etc.
| Model | Rated evaporation capacity (t/h) | Working pressure (Mpa) | Thermal Efficiency (%) | Fuel consumption (Kg/h) | Overall dimension L×W×H (mm) | Weight (t) |
| DZH0.5-0.7/1.0-T | 0.5 | 0.7/1.0 | 78 | 150 | 3228×2000×2656 | 8 |
| DZH1-0.7/1.0/1.25-T | 1 | 0.7/1.0/1.25 | 80 | 301 | 4108×2200×2915 | 12 |
| DZH2-0.7/1.0/1.25/1.6-T | 2 | 0.7/1.0/1.25/1.6 | 80 | 602 | 4700×2300×3270 | 15 |
| DZH4-1.25/1.6-T | 4 | 1.25/1.6 | 80 | 1190 | 5600×2550×3563 | 22 |
| Note: 1. Parameter is for reference only, if any changes should follow the factory technical data. 2. Our company can design boiler products based on customers’ requirement and different biomass fuels. | ||||||
